GMC Sierra 2500HD Model News |
| The GMC Sierra 2500HD and 3500HD roll into 2025 with minimal changes. |
GMC Sierra 2500HD Model Highlights |
| The Sierra HD comes in one of several different body styles with long and short bed options. However, despite this complexity there are only two available engines, both V8 units displacing 6.6 liters. The gasoline option makes 401 horsepower and 464 lb-ft of torque. The more expensive diesel engine is aided by a turbocharger and makes 470 horsepower and a massive 975 lb-ft of torque. Unlike the gasoline engine, the diesel is mated to a 10-speed automatic to handle all that torque. When properly equipped, a Sierra HD 3500 should be able to tow up to 35,000lbs with a 5th wheel attachment, or 20,000 lbs with a traditional trailer hitch, thanks in large part to the massive torque produced by its diesel V8. Sierra HD models are available with either rear-wheel drive of selectable four-wheel drive.
The Sierra HD comes in either 2500 form or 3500 form with 3500 versions offering a bit more towing capacity and payload because they can be optioned with a "dually" setup, giving the truck an extra pair of wheels on the rear axle. Both trucks can be optioned with a regular cab, a double cab featuring four conventional doors, or a crew cab with even bigger rear seats. Truck beds are either 6'9" or 8' depending on configuration, though the only restriction to bed size is in the regular cab version, which always comes with the longer bed.
In addition to copious options for the basic architecture of the truck, Sierra buyers are also offered plenty of choices when it comes to the tech in their new vehicle. GMC's ProGrade Trailering system features fifteen camera views to help keep an eye on things behind the truck, even counting a class exclusive transparent trailer view among its features. The available heads up display on the Sierra HD is massive, measuring 15-inches across, while the rear-view mirror can be switched between displaying an actual mirror and the view from the rearward facing camera. GM claims their MultiPro tailgate is the world's first six-function tailgate. In practice that means it's easy to load things into and out of the back of the truck, while also providing a ton of utility options for carrying loads with the tailgate dropped. It also has a built-in step to make it easier to climb in and out of the bed of the truck.
Concentrating on off-roading capabilities, 4AT models come standard with four-wheel drive along with a more off-road biased suspension setup that includes Rancho Shocks. Other standard features on the 4AT include skid plates, an Eaton locking differential, Michelin all-terrain tires, a heads-up display, GMC's HD Surround Vision camera system, hill descent control and an off road mode.
Most buyers though, will probably opt for the Denali version of the Sierra HD. Available in both 2500 and 3500 forms, Denali versions of the Sierra HD come standard with the bigger crew cab, body colored front and rear bumpers, LED lights in the cargo bed, tinted glass, LED headlights, daytime running, front fog and taillights, powered external mirrors, a MultiPro tailgate, UltraSonic front and rear parking sensors, Lane Departure Warning, Lane Change Alert with Automatic Braking, Rear Cross-Traffic Alert, Following Distance Indicator and Hill Descent Control (HDC).
The Denali Interior features include, 4G LTE Wi-Fi, Bluetooth and Apple CarPlay\Android Auto connectivity, a 13.4-inch infotainment screen and a 12.3-inch digital instrument cluster, a 7-speaker sound system, dual-zone climate control, heated front and rear seats, vented front seats, a heated steering wheel, keyless start and wireless device charging. |
GMC Sierra 2500HD Pros |
| The GMC Sierra HD competes with the RAM 2500 and 3500 as well as the Ford F-250 and F-350. The Sierra costs a bit more than its competitors, but it comes with a bigger and more powerful engine than the Ford, while the Dodge is significantly cheaper for the stripped down 'Tradesman' trim level. In addition to its robustness, the Sierra comes with a ton of tech to make trailering easier, including an available camera system that utilizes no fewer than fifteen cameras. Meanwhile, those who want all that functionality with a good dose of comfort, will find no better truck than the upscale Denali versions of the Sierra HD. |
GMC Sierra 2500HD Value Writeup |
| Towing capacity; interior space; well thought out technology; available off-road equipment; powerful engine options; upscale Denali edition |
Exterior
- Bed Step, Black integrated on forward portion of bed on driver and passenger side (Not available on (ZW9) pickup bed delete.)
|
- Bumper, front chrome lower
|
- Bumper, rear chrome with bumper CornerSteps
|
- Cargo tie downs (12), fixed, rated at 500 lbs per corner
|
|
- Door handles, Black grained
|
- Glass, solar absorbing, tinted
|
- Grille (Chrome with flat black grille insert bars.)
|
- Headlamps, Animated LED projectors LED turn signals and Daytime Running Lamps
|
- IntelliBeam, automatic high beam on/off (Included and only available with (PDI) Sierra HD Pro Safety.)
|
- Lamps, cargo area cab mounted integrated with center high mount stop lamp, with switch in bank on left side of steering wheel
|
- Mirrors, outside high-visibility vertical trailering lower convex mirrors, manual-folding/extending (extends 3.31" [84.25mm]), molded in Black (Not available on Regular Cab models.)
|
- Moldings, beltline, Black
|
- Tailgate and bed rail protection caps, top (Deleted with (ZW9) pickup bed delete.)
|
- Tailgate, gate function manual, no lift assist (Deleted with (ZW9) pickup bed delete.)
|
- Tailgate, locking, utilizes same key as ignition and door (Included and only available with (QK1) standard tailgate. Deleted with (ZW9) pickup bed delete.)
|
- Tailgate, standard (Deleted with (ZW9) pickup bed delete.)
|
- Taillamps, LED Signature Tail, Incandescent Brake, Turn & Reverse Lamps
|
- Tire carrier lock keyed cylinder lock that utilizes same key as ignition and door (Deleted with (ZW9) pickup bed delete.)
|
- Tire, spare LT245/75R17E all-season, blackwall (Included and only available with (QHQ) LT245/75R17E all-season, blackwall tires with (E63) pickup bed models. Available to order when (ZW9) pickup bed delete and (QHQ) LT245/75R17E all-season, blackwall tires are ordered.)
|
- Tires, LT245/75R17E all-season, blackwall
|
- Wheels, 17" (43.2 cm) painted steel, Silver (Not currently available to order.)
|
Safety
- Airbags, Dual-stage frontal airbags for driver and front outboard passenger; Seat-mounted side-impact airbags for driver and front outboard passenger; Head-curtain airbags for front and rear outboard seating positions; Includes front outboard Passenger Sensing System for frontal outboard passenger airbag (Always use seat belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
|
- Automatic Emergency Braking (Included and only available with (PDI) Sierra HD Pro Safety.)
|
- Buckle to Drive prevents vehicle from being shifted out of Park until driver seat belt is fastened; times out after 20 seconds and encourages seat belt use (Included and only available with (PDI) Sierra HD Pro Safety.)
|
- Daytime Running Lamps, LED signature lighting
|
- Following Distance Indicator (Included and only available with (PDI) Sierra HD Pro Safety.)
|
- Forward Collision Alert (Included and only available with (PDI) Sierra HD Pro Safety.)
|
- Front Pedestrian Braking (Included and only available with (PDI) Sierra HD Pro Safety.)
|
- HD Rear Vision Camera (Not available with (ZW9) pickup bed delete. Removed with (UV2) HD Surround Vision or (ZW9) pickup bed delete. Not available with (Z6A) Gooseneck / 5th Wheel Prep Package.)
|
- Hitch Guidance dynamic single line to aid in truck trailer alignment for hitching (Deleted with (ZW9) pickup bed delete.)
|
- Lane Departure Warning (Included and only available with (PDI) Sierra HD Pro Safety.)
|
|
- OnStar Basics (OnStar Fleet Basics for Fleet) Drive confidently with core OnStar services including select remote commands, built-in voice assistance, real-time traffic and navigation, and Automatic Crash Response to help if you're in need. (OnStar Basics includes select remote commands, Navigation, Voice Assistance, and Automatic Crash Response, for eligible vehicles with compatible software. For MY25 vehicles, OnStar Basics is standard for 8 years; OnStar plan, working electrical system, cell reception and GPS signal required. OnStar links to emergency services. Service coverage varies with conditions and location. Service availability, features and functionality vary by device and software version. See onstar.com for details and limitations.)
|
- OnStar Services capable (See onstar.com for details and limitations. Services vary by model. Service plan required.)
|
- Rear Seat Belt Indicator (Requires Crew Cab or Double Cab model.)
|
- Seat Belt Adjustable Guide Loops, front row only (Included and only available on Crew Cab and Double Cab models. Not available with (ZW9) pickup bed delete.)
|
- StabiliTrak, stability control system with Proactive Roll Avoidance and traction control, includes electronic trailer sway control and hill start assist
|
- Teen Driver a configurable feature that lets you activate customizable vehicle settings associated with a key fob, to help encourage safe driving behavior. It can limit certain available vehicle features, and it prevents certain safety systems from being turned off. An in-vehicle report card gives you information on driving habits and helps you to continue to coach your new driver
|
- Tire Pressure Monitoring System, auto learn includes Tire Fill Alert (does not apply to spare tire)
|
- Trailering Information Label provides max trailer ratings for tongue weight, conventional, gooseneck and 5th wheel trailering (Not available on (ZW9) pickup bed delete.)
|
Paint | Invoice | MSRP | | |
| SUMMIT WHITE | - | - | | |
| CARDINAL RED (Available at extra charge.) | $450 | $495 | | |
| DOWNPOUR METALLIC (Available at extra charge. Not available on 3SA.) | $450 | $495 | | |
| ONYX BLACK (Available at extra charge.) | $450 | $495 | | |
| STERLING METALLIC (Available at extra charge.) | $450 | $495 | | |
| THUNDERSTORM GRAY (Available at extra charge.) | $450 | $495 | | |
| | | | |
| | | | |
| | | | |
| Curb Weight - Front (lbs) | 3703 |
| Curb Weight - Rear (lbs) | 2810 |
| Gross Axle Wt Rating - Front (lbs) | - TBD - |
| Gross Axle Wt Rating - Rear (lbs) | - TBD - |
| Gross Combined Wt Rating (lbs) | 24500 |
| Gross Combined Wt Rating (lbs) | 26000 |
| Gross Combined Wt Rating (lbs) | 27500 |
| Gross Combined Wt Rating (lbs) | 30000 |
| Gross Vehicle Weight Rating Cap (lbs) | 10000 |
| Gross Vehicle Weight Rating Cap (lbs) | 10150 |
| Gross Vehicle Weight Rating Cap (lbs) | 10800 |
| Gross Vehicle Weight Rating Cap (lbs) | 11050 |
| Gross Vehicle Weight Rating Cap (lbs) | 11500 |
| Axle Capacity - Front (lbs) | - TBD - |
| Axle Capacity - Rear (lbs) | - TBD - |
| Axle Ratio (:1) - Front | |
| Axle Ratio (:1) - Rear | 3.42 |
| Axle Ratio (:1) - Rear | 3.73 |
| Axle Type - Front | - TBD - |
| Axle Type - Rear | - TBD - |
| Shock Absorber Diameter - Front (mm) | 2.01 |
| Shock Absorber Diameter - Rear (mm) | 2.01 |
| Spring Capacity - Front (lbs) | - TBD - |
| Spring Capacity - Rear (lbs) | - TBD - |
| Stabilizer Bar Diameter - Front (in) | 1.38 |
| Stabilizer Bar Diameter - Rear (in) | |
| Suspension Type - Front | Short/Long Arm |
| Suspension Type - Rear | Multi-Leaf Springs |
| Total Cooling System Capacity (qts) | - TBD - |
| EPA Fuel Economy Est - City (MPG) | |
| EPA Fuel Economy Est - Hwy (MPG) | |
| Fuel Economy Est-Combined (N/A) | |
| Cold Cranking Amps @ 0? F (2nd) | |
| Cold Cranking Amps @ 0? F (2nd) | 700 |
| Cold Cranking Amps @ 0? F (Primary) | 720 |
| Cold Cranking Amps @ 0? F (Primary) | 730 |
| Maximum Alternator Capacity (amps) | 170 |
| Maximum Alternator Capacity (amps) | 220 |
| Maximum Alternator Capacity (amps) | 220 & 170 |
| Maximum Alternator Watts | N/A |
| Clutch Size (in) | N/A |
| Drivetrain | Rear Wheel Drive |
| Eighth Gear Ratio (:1) | - TBD - |
| Eighth Gear Ratio (:1) | 0.85 |
| Fifth Gear Ratio (:1) | - TBD - |
| Fifth Gear Ratio (:1) | 1.48 |
| First Gear Ratio (:1) | - TBD - |
| First Gear Ratio (:1) | 4.54 |
| Fourth Gear Ratio (:1) | - TBD - |
| Fourth Gear Ratio (:1) | 1.72 |
| Ninth Gear Ratio (:1) | - TBD - |
| Ninth Gear Ratio (:1) | 0.69 |
| Reverse Ratio (:1) | - TBD - |
| Reverse Ratio (:1) | 4.54 |
| Second Gear Ratio (:1) | - TBD - |
| Second Gear Ratio (:1) | 2.87 |
| Seventh Gear Ratio (:1) | - TBD - |
| Seventh Gear Ratio (:1) | 1.00 |
| Sixth Gear Ratio (:1) | - TBD - |
| Sixth Gear Ratio (:1) | 1.26 |
| Tenth Gear Ratio (:1) | - TBD - |
| Tenth Gear Ratio (:1) | 0.63 |
| Third Gear Ratio (:1) | - TBD - |
| Third Gear Ratio (:1) | 2.06 |
| Trans Description Cont. | Automatic |
| Trans Description Cont. Again | |
| Trans Order Code | MGM |
| Trans Order Code | MGU |
| Trans Order Code | MKM |
| Trans Power Take Off | |
| Trans Power Take Off | Yes |
| Trans PTO Access | |
| Trans PTO Access | - TBD - |
| Trans Type | 10 |
| Transfer Case Gear Ratio (:1), High | |
| Transfer Case Gear Ratio (:1), Low | |
| Transfer Case Model | |
| Transfer Case Power Take Off | |
| Transfer Case Power Take Off | - TBD - |
| Brake ABS System | 4-Wheel |
| Brake ABS System (Second Line) | |
| Brake Type | Pwr |
| Disc - Front (Yes or ) | Yes |
| Disc - Rear (Yes or ) | Yes |
| Drum - Rear (Yes or ) | |
| Front Brake Rotor Diam x Thickness (in) | 14 x 1.6 |
| Rear Brake Rotor Diam x Thickness (in) | 14.1 x 1.3 |
| Rear Drum Diam x Width (in) | |
| Displacement | 6.6L/- TBD - |
| Engine Oil Cooler | - TBD - |
| Engine Order Code | L5P |
| Engine Order Code | L8T |
| Engine Type | Gas V8 |
| Engine Type | Turbocharged Diesel V8 |
| Fuel System | Direct Injection |
| SAE Net Horsepower @ RPM | 401 @ 5200 |
| SAE Net Horsepower @ RPM | 470 @ 2800 |
| SAE Net Torque @ RPM | 464 @ 4000 |
| SAE Net Torque @ RPM | 975 @ 1600 |
Warranty
Warranty:<<< Preliminary 2025 Warranty >>> Note Basic:3 Years/36,000 Miles/km Corrosion:3 Years/6 Years/100,000 Miles/km/36,000 Miles/km
|
|
